Home >>  Products >> Water-Ring Vacuum Pumps/Compressors

Vacuum, Vacuum Pumps, Vacuum Exhavsters, Paper Mill Machinery Manufactures/Suppliers,Used Machinery, Power Plant Machinery, Sugar Mill Machinery, Pumps, Blowers, Twin Lobe blowers, Compressors, Hign Vacuum Pumps, Refiners, Tri-Disc Refiners, Pulp Machinery
Click here to view Photo Gallery

MATERIAL OF CONSTRUCTION OFFERED:

Cast lron FG-260 / S.G. IRON / Phoshphorous Bronze / SS - 316 SS - 304 / SS - 316 L Rubber Lined / Cast Steel / Alloy 20 in Complete as well as Partial Vacuum Pumps.

PERFORMANCE TABLE OF "GARUDA" GWV SERIES

MODEL

MOTOR HP

 SPEED (RPM)

SUCTION
CAPACITY m3 / hr

WATER LPM.
GWV 10

1.0

2880

10

1.2
GWV 20

2.0

2880

20

2.0
GWV 40

3.0

2880

53

4.0
GWV 70

5.0

2880

85

9.0
GWV 120

7.5

2880

125

13.0
GWV 150

7.5

1440

175

16.0
GWV 200

10.0

1440

225

20.0
GWV 300

15.0

1440

340

28.0
GWV 400

20.0

1440

450

35.0
GWV 500

25.0

980

525

45.0
GWV 600

30.0

980

730

55.0
GWV 1000

40.0

980

1100

85.0
GWV 1500

75.0

725

1725

120.0
GWV 2000

100.0

725

2200

150.0
